DMCA01 Multifunctional Mobile Digital C-arm System Portable X-Ray Machine 5Kw With Workstation Radiography Equipment
Model: PSKU0154
1. Features:1) Electric source (V): AC110/2202) Power(kw): 53) Spatial Resolution(lp/mm): 2.54) Pixel Matrix( pixels): 1024x10245) Pixel Pitch(um): 2056) Removable grid: Yes7) Active area(mm): 210x2108) Data Interface: 1G Ethern...
Product Parameters
| Parameter | Description |
|---|---|
| Product Name | DMCA01 Multifunctional Mobile Digital C-arm System Portable X-Ray Machine 5Kw With Workstation Radiography Equipment |
| SKU | PSKU0154 |
| Size | 2120*965*450-740mm |
| Packing Size of set | 2090*1100*430mm (1 set per carton) |
| Loading capacity | 250kg / 551lbs |
Product Description
1. Features:
1) Electric source (V): AC110/220
2) Power(kw): 5
3) Spatial Resolution(lp/mm): 2.5
4) Pixel Matrix( pixels): 1024×1024
5) Pixel Pitch(um): 205
6) Removable grid: Yes
7) Active area(mm): 210×210
8) Data Interface: 1G Ethernet
9) ms range (ms): 10-1600
10) Mas range(mAs): 0.2-100
11) Focal spots(mm): 0.3/0.6
12) SID(mm): 1000
13) Free space in arc( mm): 784
14) Depth in arc( mm): 640
15) Orbital rotation(°): 150 (117/-33)
16) Lateral rotation(°): 360 (±1 80)
17) wig/wag(°): ±15
https://images.51microshop.com/15822/video/DMCA01.mp4
