DMDR03 25KW High Frequency Mobile Digital X-ray Radiography Medical Diagnostic Equipment For Emergency Room
Model: PSKU0152
1. Features:1) Max output power: 25kW2) Main Inverter Frequency: 60kHz3) Focus: Small focus: 0.6; Large focus: 1.34) Rotation anode speed: 3000rpm5) Heat capacity: 900kJ(1200kHU)6) Tube curent: 200mA7) Tube voltage: 40-125kV8) M...
Product Parameters
| Parameter | Description |
|---|---|
| Product Name | DMDR03 25KW High Frequency Mobile Digital X-ray Radiography Medical Diagnostic Equipment For Emergency Room |
| SKU | PSKU0152 |
| Size | 2120*965*450-740mm |
| Packing Size of set | 2090*1100*430mm (1 set per carton) |
| Loading capacity | 250kg / 551lbs |
Product Description
1. Features:
1) Max output power: 25kW
2) Main Inverter Frequency: 60kHz
3) Focus: Small focus: 0.6; Large focus: 1.3
4) Rotation anode speed: 3000rpm
5) Heat capacity: 900kJ(1200kHU)
6) Tube curent: 200mA
7) Tube voltage: 40-125kV
8) MAS: 0.4-360mAs
9) Detector: Amorphous silicon detector
10) scintillator: cesium iodide
11) View: 14″x17”(35*43cm)
12) Max spatial resolution: 2304*2816
13) Pixel size: 3 Lp/mm
https://images.51microshop.com/15822/video/DMDR03.mp4
