Product Description

1.Features:

1)Using the full dry technology,  makes diagnostic more convenient

2)The probe adopt the Technology of the United States DuPont, makes the probe to receive higher sensitivity and better reception

3)The better ultrasonic frequency on the measuring position, with better penetrability, more effective signal

4)Use the ultrasonic axial conduction technology, double emission and double receiving, it can provide more effective data

5)With innovative algorithm, effectively remove clutter and jamming signal, to  get the valid data

2.Performance parameter:

1)Measurement parts: radius and Tibia

2)Measurement  mode: double emission and double receiving

3)Measurement  Accuracy : ≤0.25%

4)Measurement Reproducibility:  ≤0.25%

5)Measurement  time:Three Cycles adults measuring time <15 seconds, Three Cycle Children measuring time < 3seconds

6)Probe frequency : 1.20MHz

7)External medical special power supply, power>60W

8)Main unit weight< 4kgs, easy to carry

9)Size(cm): 49cm×34.5cm×44.5cm ,G.W.11Kgs ,N.W: 5 Kgs
