DMHX21 Hot sale & high quality Medical Ventilator Breathing Machine with 10.4-inch TFT Color LCD Screen Display
Model: PSKU0302
Specification:1. Display mode: 10.4-inch High-definition TFT color LCD screen display2. Ventilation mode: VCV ,PCV,SIMV,PSV, PSV+SIMV, CPAP3. Ventilation function: PEEP、SIGH、standby、IP、IRV4. Tidal volume: 20~1800ml5. Rate: 2~120b...
Product Parameters
| Parameter | Description |
|---|---|
| Product Name | DMHX21 Hot sale & high quality Medical Ventilator Breathing Machine with 10.4-inch TFT Color LCD Screen Display |
| SKU | PSKU0302 |
| Size | 2120*965*450-740mm |
| Packing Size of set | 2090*1100*430mm (1 set per carton) |
| Loading capacity | 250kg / 551lbs |
Product Description
Specification:
1. Display mode: 10.4-inch High-definition TFT color LCD screen display
2. Ventilation mode: VCV ,PCV,SIMV,PSV, PSV+SIMV, CPAP
3. Ventilation function: PEEP、SIGH、standby、IP、IRV
4. Tidal volume: 20~1800ml
5. Rate: 2~120bpm
6. Pressure trigger sensitivity: -10~10cmH20
7. Flow trigger sensitivity: 1~20L/min
8. PEEP: 0~25cmH20
9. Pressure range: 3~50cmH20
10. Pressure limitation: 5~60cmH20
11. Flow rate setting: 1~10gear
12. Expiratory trigger sensitivity: 10%~90%
13. Time control: 1~10s
14. Oxygen concentration: 21%~99%
