Product Description

Specification:

1. VentilationMode: SIPPV、MANUAL

2. Tidal Volume: Adjustment Range:50~1500mL,Display Range:0~1500mL

3. Respiratory Frequency: 4~40bpm

4. Inspiratory Pressure Trigger: -1.0~1.0kPa

5. I:E Ratio: 1:1.5~1:4.0

6. Alarm: Tidal volume,Airway pressure,Power failure,Oxygen failure,etc

7. Operating modes: Pneumatically driven & electronically controlled, closed semi-closed and semi-open

8. Anesthesia Ventilator: Built-in high visibility, wide angle LED alphanumeric data display

9. Standard integrated metallic modular respiratory circuit, completely solves the problem of gas sealing under high temperature disinfection, easy to clean and disinfect

10. High precision two tube flowmeter, fitted with interlocking oxygen-nitrous oxide supply, guarantees oxygen output is never lower than 21%

11. Power Failure Support Functions: Automatically converts to backup power mode during AC power outages

12. Fully metallic frame, precise construction, elegant design, equipped with automated self-checking function during startup and an automatic self-calibrating sensor

13. Equipped with infrared turbine flow sensor, precisely measures gas flows. stable and reliable
