DMRX02 High Frequency Full Field Digital Mammography System X-Ray Machine Medical Imaging Equipment
Model: PSKU0162
1. Features:1) Maximum output power: 5KW2) Output voltage range: 20-40kv3) Output current range: 10ma-160ma4) Loading time range: 0.005s-10s5) Current time product regulation range: 0.5-560mas6) With exposure control system, sup...
Product Parameters
| Parameter | Description |
|---|---|
| Product Name | DMRX02 High Frequency Full Field Digital Mammography System X-Ray Machine Medical Imaging Equipment |
| SKU | PSKU0162 |
| Size | 2120*965*450-740mm |
| Packing Size of set | 2090*1100*430mm (1 set per carton) |
| Loading capacity | 250kg / 551lbs |
Product Description
1. Features:
1) Maximum output power: 5KW
2) Output voltage range: 20-40kv
3) Output current range: 10ma-160ma
4) Loading time range: 0.005s-10s
5) Current time product regulation range: 0.5-560mas
6) With exposure control system, support one key exposure or hand brake exposure.
7) Anode heat capacity: 300KHU
8) Anode rotating speed: 10000 rpm
9) Anode material: Molybdenum
10) Nominal focus size: small focus 0.1mm, large focus 0.3mm
11) Imaging medium: amorphous silicon
12) Imaging size: 240mm × 300mm
13) Conventional spatial resolution: 7.0lp/mm
14) Pixel matrix: 2816 x 3528
15) A / D conversion: 16 bits
16) Pixel size: 85 μm
https://images.51microshop.com/15822/video/DMRX03_(2).mp4
