DMS03 Top Quality Semi-auto Chemistry Analyzer with Large color LCD with touch screen

Model: PSKU0193

Specification:1. 10 incubators at 37°C, 30°C or 25°C, ± 0.1°C, 3 timers with alarm 2. 6V/10W Halogen Lamp with long life span3.  Light path 10 mm4. 7 wavelengths, 340, 405, 492, 510, 546, 578 and 630 nm 5. Precision ± 2 nm, width ...

Share:

Facebook Twitter Pinterest WhatsApp Email
Add to Inquiry

Product Parameters

Parameter Description
Product Name DMS03 Top Quality Semi-auto Chemistry Analyzer with Large color LCD with touch screen
SKU PSKU0193
Size 2120*965*450-740mm
Packing Size of set 2090*1100*430mm (1 set per carton)
Loading capacity 250kg / 551lbs

Product Description

Specification:

1. 10 incubators at 37°C, 30°C or 25°C, ± 0.1°C, 3 timers with alarm

2. 6V/10W Halogen Lamp with long life span

3.  Light path 10 mm

4. 7 wavelengths, 340, 405, 492, 510, 546, 578 and 630 nm
5. Precision ± 2 nm, width ≤ 10nm
6. Absorbance range 0 to 4.5 Abs
7. 32 μL quartz flowcell
8. Sample volume 500 to 3000 μL
9. Carryover ≤ 1%
10. 112 programmable assays
11. Data Storage ≥ 10,000 sample results
12. Quality control program X, SD, CV%, L-J graph
13. 7-inch color LCD with touch screen
14. ARM series high speed micro CPU
15. Built-in thermal printer
16. RS-232 interface
17. Working temperature 10-30°C
18. Humidity ≤ 80%
19. Power supply 100~240 VAC, 50-60Hz, 100VA
20. Dimension 340mm*270mm*185mm (L*W*H)
Features:
1. Large color LCD with touch screen
2. Built-in incubators and timers
3. Flow cell and cuvette mode
4. Real-time display of reaction curve
5. Substrate depletion detection
6. Reliable optical system
7. Light source auto sleep function
