Product Description

1.Specifications:

1)Ideal for today’s advance ultrasound systems

2)User-friendly controls on front panel with addition of jog dial

3)Hybrid – accepts both analog and digital signal input

4)High resolution of 325 DPI

5)Compact, space-saving design

6)High speed printing of approximately 1.9 seconds

7)Utilizes existing 110 Series media by Sony: UPP-110S/5, UPP-110HD, UPP-110HG

8)Input connector: VIDEO IN (BNC type) NTSC or PAL composite video signals 1.0 Vp-p, 75 ohms (NTSC/PAL automatically discriminated)

9)Output connector: VIDEO OUT (BNC type) Loop-through

10)Remote connector: stereo mini jack

11)Power requirements:100 to 240V AC, 50/60Hz

12)Input current(Stand by):1.3A to 0.6A (0.10A to 0.05A)

13)Operating conditions:Temperature:41°F to 104°F / 5°C to 40°C , Humidity:20% to 80% (noncondensing)

14)Dimensions (W x H x D) 6 1/8in x 3 1/2in x 9 1/2in (154mm x 88mm x 240mm)

15)Weight:5lb 8oz (2.6kg)
