Product Description

Supported Probes:

1. 3C6A: 3.5MHz/R60/convex array probe;

2. 7L4A: 7.5MHz/L38mm/line array probe.

3. 6C15A: 6.5MHz/R15/Micro convex probe;

4. 6E1A: 6.5MHz/R10/Intracavity probe;

5. 6I7A: 6MHz/L64mm/rectal probe

6.Probe frequency: 2.5-10MHz

7.Probe sockets:≥2

Batteries:Built-in 7000 mAh lithium battery, working condition, continuous working time ≥ 1 hour or more, the screen provides power display information

Internal hard disk:Supports hard disk (≥128GB)

 Main technical parameters and functions:

 Fully digital imaging technology:

1. Multi-beam synthesis

2. Real-time point-by-point dynamic focusing imaging

3. Pulsed inverse harmonic composite imaging

4. Space composite

5. Image Enhancement Noise Reduction

Imaging mode:

1. Model B

2. M-mode

3. Color (color multispectral) mode

4. PDI (Power Doppler) mode

5. PW (Pulse Doppler) mode

Image Display Mode:

B, Dual-width, 4-width, B+M, M, B+Color, B+PDI, B+PW, PW, B+Color+PW, B+PDI+PW, ★B/BC Dual Real-time

Supported frequencies:

B/M: fundamental frequency ≥ 3 steps; harmonic frequency ≥ 2 steps;

Color/PDI:≥2steps

PW:≥2speeds

Image parameter:

Model B:

1. Grayscale mapping: ≥15 steps

2. Noise suppression: ≥8 steps

3. Frame correlation: ≥8 steps

4. Edge Enhancement: ≥8 steps

5. Image Enhancement: ≥5 steps

6. Spatial composite: switch adjustable

7. Scanning density: high, medium, low

8. Image flip: up, down, left, right

9. Maximum scanning depth: ≥320mm

M-mode:

1. Scanning speed (Sweep Sleep):≥ 5 adjustable steps

2. Line Average:≥8 steps

Color/PDI mode:

1. PRF: ≥15 steps, 0.6KHz – 11.7KHz

2. Color map: ≥4 types

3. Color correlation: ≥8 steps

4. Post-processing: ≥4 grades

PW mode:

1. SV size/position: SV size 1.0-8.0mm adjustable

2. PRF: ≥16 steps, 0.7kHz-9.3KHz adjustable

3. Scanning speed (Sweep Sleep): ≥ 5 adjustable steps

4. Correction Angle: -85°~85° in 5° steps

5. Spectrogram flip: switch adjustable

6. Wall filter: ≥ 4 adjustable steps

7. Multi-spectral sound: ≥ 20 stops
