Product Description

1.Portable color ultrasound size and weight:

1). Dimensions of mainframe: W400mm*H394mm*Thick172mm

2). Package size: 46cm (L) × 46cm (W) × 31cm (H)

3). Weight of main unit: 8kg;

4). Packaging weight: 12kg, including: host + two probes + power cord + manual + carton + foam.

2.Fully digital imaging technology:

1). Multi-beam synthesis

2). Real-time point-by-point dynamic focusing imaging

3). Pulsed inverse harmonic composite imaging

4). Space composite

5). Image Enhancement Noise Reduction

3. Imaging modes:

1). B-mode

2). M-mode

3). Color (color multispectral) mode

4). PDI (Power Doppler) mode

5). PW (Pulse Doppler) mode

4.Supported Probes:

1).3C6C:3.5MHz/R60/128-array convex array probe

2).7L4C:7.5MHz/L38mm/128-array line probe

3).10L25C:10MHz/25mm/128-array line array probe

4).6E1C:6.5MHz/R10/128-array intracavity probe

5).6C15C:6.5MHz/R15/128 array element micro-convex probe

6).3C20C:3.5MHz/R20/128 array element micro-convex probe

7).6I7C:6MHz/L64mm/128 array rectal probe

8).6E1C:6.5MHz/R10/128 array element visual abortion probe

9).2P2F:2.5MHz/L16mm/64-array low-frequency phased array probe

5.Probe frequency:

1)2.5-14.5MHz

2)Probe socket: ≥2

6.Supported frequencies:

1)B/M: fundamental frequency ≥ 3 steps; harmonic frequency ≥ 2 steps;

2)Color/PDI: ≥2 steps

3)PW:≥2 speeds

4)Movie Playback:

5)1.2D mode,B max:≥5000 frames,Color,PDI max:≥2300 frames;

6)Timeline mode (M,PW), maximum: ≥190s

7.Image Enlargement:

1)Real-time scanning (B, B+C, 2B, 4B), status: infinitely zoomable

8.Batteries:

1)Built-in high-capacity lithium battery, working condition, continuous working time ≥ 1.5 hours, the screen provides power display information

9.Image parameters:B model:

1). Gray scale mapping: ≥15 steps

2). Noise suppression: ≥8 steps

3). Frame correlation: ≥8 grades

4). Edge enhancement: ≥8 steps

5). Image enhancement: ≥5 steps

6). Space composite: switch adjustable

7). Scanning density: high, medium, low

8). Image flip: up and down, left and right

9). Maximum scanning depth: ≥320mm

M model:

1). Scanning speed (SweepSleep): ≥5 adjustable steps

2). LineAverage: ≥8 grades

Color/PDI mode:

1).PRF: ≥15 steps, 0.6KHz-11.7KHz

2). Color map (colormap): ≥ 4 types

3). Color related: ≥8 grades

4). Post-processing: ≥4 grades
