DMU14 Full Digital Ultrasound Scanner Trolley B/W Ultrasound Machine

Model: PSKU0014

1.Main specifications and system overview:1)Operation System：AARM chip, stable, simple and powerful 2)2 Active Probe ports3)Scan Mode：B、B+B、B+M、M、4B；4)Display：15inch high-definition medical grade LED display5)Language：CN、EN、FR、RU、...

Share:

Facebook Twitter Pinterest WhatsApp Email
Add to Inquiry

Product Parameters

Parameter Description
Product Name DMU14 Full Digital Ultrasound Scanner Trolley B/W Ultrasound Machine
SKU PSKU0014
Size 2120*965*450-740mm
Packing Size of set 2090*1100*430mm (1 set per carton)
Loading capacity 250kg / 551lbs

Product Description

1.Main specifications and system overview:
1)Operation System：AARM chip, stable, simple and powerful
2)2 Active Probe ports
3)Scan Mode：B、B+B、B+M、M、4B；
4)Display：15inch high-definition medical grade LED display
5)Language：CN、EN、FR、RU、SP、PT
6)Size：58*68*124cm
7)Net Weight：34KG
8)Package Size：75*64*95cm
9)Gross Weight：41KG
2.Probe：
1)Convex Probe Depth Adjust Level:≥15，Depth:70-268mm；Frequency:2.0-5.0MHz
2)Linear Probe Depth Adjust Level:≥15，Depth:55-173mm；Frequency:5.5-9.0MHz
3)Transvaginal Probe Depth Adjust Level:≥10，Depth: 40-90mm；Frequency:7.0-10.0MHz
3.52D mode：
1)Gain：0－127，visible and adjustable
2)TGC：8 level adjustable
3)Dynamic range：0-127db
4)Scanning angle：80-100
5)Frame Related:4 level, visible and adjustable
6)Edge enhancement：4 level,visible and adjustable
7)Post processing：8 level, visible and adjustable
8)Image optimization：13 level,visible and adjustable
9)Focus number：4
10)Focus position：0-15 adjustable
11)Body marks：97 kinds,Support body position indicator
12)Pseudo Color ：8
13)Stone positioning function and real-time depth measurement
14)Support Up/Down, Left/Right, Black/White
15)M mode scan speed：8 level, visible and adjustable
16)Time Setting：Time/Date/Time Format/Date Format
17)Supports 5 groups of function key adjustments for commonly used parameters
18)Puncture function：3 level Adjustable
19)Clear screen: Clear measurement marks,results, annotations, body markers and other information in the image area
20)Comments: support English uppercase and lowercase
3.Images management system:
1)Picture Saving format：BMP
2)Cine loop：≥256 frames
3)Support to export images into USB flash
4.Configuration:
1)DW-350 Trolley Ultrasonic Diagnostic System host*1
2)Probe options ：C2-6R60 Convex probe、L7-10L40 Linear probe、C5.5-7.5R13
3)Transvaginal probe
4)Optional: Sony printer
