DMU16 Portable doppler 3D 4D Ultrasound Ultrasonic DiagnosticPortable Ultrasound Machine

Model: PSKU0016

Main specifications and system overview:1 Operating system: Windows 102 Spectral Pulse Doppler (PW) 3.Directional Energy Doppler 4.Real-time triple synchronization 5.Spatial composite imaging 6.Tissue harmonic imaging 7.2B/4B imag...

Share:

Facebook Twitter Pinterest WhatsApp Email
Add to Inquiry

Product Parameters

Parameter Description
Product Name DMU16 Portable doppler 3D 4D Ultrasound Ultrasonic DiagnosticPortable Ultrasound Machine
SKU PSKU0016
Size 2120*965*450-740mm
Packing Size of set 2090*1100*430mm (1 set per carton)
Loading capacity 250kg / 551lbs

Product Description

Main specifications and system overview:
1 Operating system: Windows 10
2 Spectral Pulse Doppler (PW)
3.Directional Energy Doppler
4.Real-time triple synchronization
5.Spatial composite imaging
6.Tissue harmonic imaging
7.2B/4B imaging mode
8.System language supports: Chinese, English, French, Russian and Spanish, five languages
9.Monitor: ≥15 inches, 0-30°adjustable
10. Integrated clipboard: display the saved images at the bottom of the screen, which can be directly transferred or deleted
11.The system has the function of field upgrade
12. Preset conditions: For different inspections, preset the inspection conditions to optimize the image, reduce the
adjustment during operation, and commonly required external adjustment and combined adjustment
13.Probe interface ≥ 2 active
14.Support real-time 3D function (3D/4D/5D HD LIVE)
15.With trapezoidal imaging function
16.With one-click intelligent optimization
Probe option:
Convex probe: frequency 2.0MHz, 2.5MHz, 3.0MHz, 3.5MHz, 4.0MHz, 5.5MHz, H4.0MHz, H5.0MHz,
eight-segment frequency conversion (depth 30-255mm)
Linear probe: Frequency: 6.0MHz, 7.5MHz, 8.5MHz, 10.0MHz, 12.0MHz, H10.0MHz, six-segment frequency
conversion (depth 20-128mm)
Trans-vaginal probe: Frequency: 4.5MHz, 5.0MHz, 6.0MHz, 6.5MHz, 7.0MHz, 9.0MHz, H8.0MHz, seven-segment
frequency conversion (depth 30-156mm)
Micro-convex probe (R15): frequency 4.5MHz, 5.0MHz, 6.0MHz, 6.5MHz, 7.0MHz, 9.0MHz, H8.0Mhz,
seven-segment frequency conversion (depth 30-111mm)
Rectal probe: frequency 4.0MHz, 6.5MHz, 9.0MHz, H8.0Mhz, four-segment frequency conversion (depth 20-110mm)
4D volume probe: frequency 2.0MHz, 3.0MHz. 4.0MHz, 4.5MHz, 5.5MHz, 6.0MHz, H5.0MHz, seven-segment
frequency conversion (depth 30-237mm)
Imaging Mode:
1.Color frame correlation: 0-12 levels, visually adjustable
2.Color spectrum: 0-7 levels, adjustable visually
3. Color conversion: adjustable
4.B/C split screen synchronous display function
5.Color baseline: 11 levels, visually adjustable
6.Color Line Density: High and Low Adjustable
7.Wall filter: 0-5 level adjustable
Spectral Doppler Mode (PW):
1.Sampling volume angle correction: -80°～80° adjustable
2.Sampling volume: 0.5mm-20mm visually adjustable
3. Frequency: 2.5MHz and 3.0Mhz can be adjusted visually
4.Baseline: 9 levels adjustable
5.Pseudo-spectrogram: 0-5
6.Display layout: ≥4 kinds of visual adjustable
7.Speed scale: 22-528cm/s (different probe ranges are different)
3D Mode:
1.Fast angle: support 0°, 90°, 180°, 270° rotation of the 3D window image;
2.Display model: single image, dual images, quad images
3.Reconstruction modes: RealSkin, surface, Max, Min, XRax;
4.Pseudo Color: 0-7 Levels Adjustable
5.Image magnification: 5 levels
6.Contrast: 0%-100%
