DMU29 A fully Digital Color Doppler Ultrasound Diagnostic System Suitable For Humans And Animals

Model: PSKU0029

1.Features:1)21.5 medical display, can be rotated,stretched and folded2)13.3 high sensitive oversized touch screen, 60 degree flip3)The control panel can be arbitrary lifted and rotated4)Five fully activated transducer interfaces ...

Product Parameters

Parameter Description
Product Name DMU29 A fully Digital Color Doppler Ultrasound Diagnostic System Suitable For Humans And Animals
SKU PSKU0029
Size 2120*965*450-740mm
Packing Size of set 2090*1100*430mm (1 set per carton)
Loading capacity 250kg / 551lbs

Product Description

1.Features:

1)21.5 medical display, can be rotated,stretched and folded

2)13.3 high sensitive oversized touch screen, 60 degree flip

3)The control panel can be arbitrary lifted and rotated

4)Five fully activated transducer interfaces are interworking

5)Rich imaging technology, a variety of imaging modes bring a comprehensive clinical application
6)Visualize user – defined presets function
2.Standard features:
1)2B/4B-Mode
2)PDI -Mode
3)Anatomic M mode
4)Trapezoidal (Linear probe)
5)Tissue Specific Imaging (TSI)
6)Frequency Composite Imaging(FCI)
3.Monitor:
1)21.5-inch high resolution color display screen
2)Resolution: 1920×1080
3)Height range 20cm adjustable
4)Rotate angle range 180°(L/R)
5)Tilt angle range 0-90°(U/D)
4.Touch Screen:
1)13.3-inch touch screen
2)Tilt around 60°
3)Resolution: 1024×800
5.Electrical power:
1)AC adapter Input:Voltage: 100-240V~,Frequency: 50/60Hz,Power Consumption: 650VA
6.Operation Environment:
1)Ambient temperature: 5~+40
2)Relative humidity: 25%~85%
7.Storage &Transport Environment:
1)Ambient temperature: -20~+55
2)Relative humidity: 10%~95%
3)Atmospheric pressure: 860hPa~1060hPa
