Product Description

1.Features:

1)High resolution medical LED monitor,15 inch

2)Large angle rotatable free arm

3)Rotatable and backlit keyboard design

4)Four active probe connectors，Can be matched with three kinds of probes (such as convex probe, linear probe, transvaginal probe)

5)Crystal clear 2D image and sensitive Color Doppler blood flow imaging system

6)Built-in large capacity hard disc, mass storage

2.Technical specifications:

1)Displaying mode:B,2B,4B,B/M,M, B/C,B/C/D,B/D,duplex,triplex, PW

2)Image processing:THI,TSF,HPRF,Storage: 16 G,Speckle-reduction,Power adjustable,Smoothing function,Image optimization,Speckled Reduction,Tissue Harmonic imaging

3)General measurement:Normal, ABD, OB, Pelvic,Urology, Cardiac, Small Parts, Vascular, MSK

4)Normal measurement:Distance，Cubage，V3L, STD_S, Area Trace, Area, Angle, CrossLine, STD D, ParalleLine

5)Small Parts:Rt/Lt_Thyroid, Rt/Lt_Testicle, Vessel, Breast

6)Scanning depth:≥250mm

7)Probe elements:128

8)Input/output ports:USB Ports,Video Port, LAN Port

9)Options:6.5Mhz Transvaginal Probe, 3.5Mhz micro convex probe, Printers

10)Applicable Printers:EPSON-L130-Series,HP-Laser Jet-1020,HP-Laser Jet-P2035,SONY_UP-D897,SONY_UP-D898MD_X898MD
