DMXD01 Hot New Products 3 Channel Electrocardiograph Machine with 7 inch High Resolution Color Touch Screen for Human
Model: PSKU0334
Specification:1. Acquisition Mode: Simultaneous 12 leads acquisition2. Measurement Range: ±5mVpp3. Input circuit: Floating; Protection circuit against Defibrillator effect4. Input Impedance: ≥50MQ5. Frequency Response: 0.05Hz~150...
Product Parameters
| Parameter | Description |
|---|---|
| Product Name | DMXD01 Hot New Products 3 Channel Electrocardiograph Machine with 7 inch High Resolution Color Touch Screen for Human |
| SKU | PSKU0334 |
| Size | 2120*965*450-740mm |
| Packing Size of set | 2090*1100*430mm (1 set per carton) |
| Loading capacity | 250kg / 551lbs |
Product Description
Specification:
1. Acquisition Mode: Simultaneous 12 leads acquisition
2. Measurement Range: ±5mVpp
3. Input circuit: Floating; Protection circuit against Defibrillator effect
4. Input Impedance: ≥50MQ
5. Frequency Response: 0.05Hz~150Hz(-3dB)
6. Sensitivity: 2.5mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV (error:±5%)
7. Time constant: ≥3.2s
8. Paper speed: 12.5 mm/s, 25 mm/s, 50 mm/s
9. Recording mode: Thermal printing system
10. Power Supply: AC:100~240V, 50/60Hz,30VA~100VA, DC:14.8V/2200mAh, built-in lithium battery
11. 7 inch high resolution color touch screen
12. 12-lead simultaneous acquisition and display
13. ECG Automatic measurement and interpretation function
14. Compact and lightweight design
15. Software upgrade via USB/SD card3
