DMXR08 High Quality stationary digital X ray machine Stationary Digital Radiography Machine DR X ray System Price
Model: PSKU0135
1. Features:1) Max Power：20kW2) Input Voltage:Single Phrase 220V±10% or two Phrase 220V±10%3) kV Range：40-125kV4) mA Range：32-320mA5) Exporsure time range：0.003-6.3s6) mAs Range：1-400mAs7) Operating Frequency：≥30kHz8) Nominal X-Ra...
Product Parameters
| Parameter | Description |
|---|---|
| Product Name | DMXR08 High Quality stationary digital X ray machine Stationary Digital Radiography Machine DR X ray System Price |
| SKU | PSKU0135 |
| Size | 2120*965*450-740mm |
| Packing Size of set | 2090*1100*430mm (1 set per carton) |
| Loading capacity | 250kg / 551lbs |
Product Description
1. Features:
1) Max Power：20kW
2) Input Voltage:Single Phrase 220V±10% or two Phrase 220V±10%
3) kV Range：40-125kV
4) mA Range：32-320mA
5) Exporsure time range：0.003-6.3s
6) mAs Range：1-400mAs
7) Operating Frequency：≥30kHz
8) Nominal X-Ray Tube Voltage：40~125KV
9) Nominal Focal Spot Value：0.6mm-1.2mm
10) Anode Input Power：large focal spot 50KW、small focal spot20KW
11) Anode Speed：2800rpm
