DMXR16 Best Selling High-Voltage Generator Mobile Animal Digital X-ray Radiography System For Veterinary Hospital
Model: PSKU0143
1. Features:1) Output Power : 32kW2) Input Voltage : 220VAC±10% 50/60Hz3) Tube Voltage Range : 40kV~150kV4) Tube Current Range : 10mA~400mA5) X-ray Tube Voltage Range : 40kV-125kV6) Nominal Focal Spot Value :2.0mm (Large Focus)7...
Product Parameters
| Parameter | Description |
|---|---|
| Product Name | DMXR16 Best Selling High-Voltage Generator Mobile Animal Digital X-ray Radiography System For Veterinary Hospital |
| SKU | PSKU0143 |
| Size | 2120*965*450-740mm |
| Packing Size of set | 2090*1100*430mm (1 set per carton) |
| Loading capacity | 250kg / 551lbs |
Product Description
1. Features:
1) Output Power : 32kW
2) Input Voltage : 220VAC±10% 50/60Hz
3) Tube Voltage Range : 40kV~150kV
4) Tube Current Range : 10mA~400mA
5) X-ray Tube Voltage Range : 40kV-125kV
6) Nominal Focal Spot Value :2.0mm (Large Focus)
7) Light Field Indicator : LED 5W
8) Rectangular X-ray Field Selection : 45cm*45cm
9) Maximum Radiation Leakage : <1mGy/h
10) Detector Technology : Amorphous Silicon
11) Scintillator : CsI
12) Active Area : 43cm*43cm(17*17 in)
13) Image Acquisition Time : 3s~5s
