DMXR18 High Frequency Medical Stationary Digital Radiography System DR X-Ray Machine For Hospital Use
Model: PSKU0145
1. Features:1) Output power: 50KW2) Inverter frequency: 385KHZ3) Output voltage range:40~150KV4) Minimum exposure time: 1ms;5) Tube current range: 10mA~630mA6) Current time product range: 0.1mAs~630mAs7) Effective collection are...
Product Parameters
| Parameter | Description |
|---|---|
| Product Name | DMXR18 High Frequency Medical Stationary Digital Radiography System DR X-Ray Machine For Hospital Use |
| SKU | PSKU0145 |
| Size | 2120*965*450-740mm |
| Packing Size of set | 2090*1100*430mm (1 set per carton) |
| Loading capacity | 250kg / 551lbs |
Product Description
1. Features:
1) Output power: 50KW
2) Inverter frequency: 385KHZ
3) Output voltage range:40~150KV
4) Minimum exposure time: 1ms;
5) Tube current range: 10mA~630mA
6) Current time product range: 0.1mAs~630mAs
7) Effective collection area: 17×17 inch
8) Pixel matrix: 3072×3072
9) Limit resolution:3.4 lp/mm
10) Lateral movement range: 190cm
11) Vertical movement range: 135cm
12) Rotate range along the vertical axis: -180 ~ +180°
13) Rotation range along the horizontal axis: -90 ~ +90°
