DMXR20 Veterinary DR Digital X-Ray Imaging System With 16 Inches HD Touch Screen For Clinics and Hospital
Model: PSKU0146
1. Features:1) Power supply voltage: single-phase three-wire2) Power frequency: 50Hz±1Hz3) Nominal current: 400ma4) Maximum output power: 32kW5) Working frequency: ≥300kHz6) Maximum peak tube voltage: 125kV7) Detector: CareRay18...
Product Parameters
| Parameter | Description |
|---|---|
| Product Name | DMXR20 Veterinary DR Digital X-Ray Imaging System With 16 Inches HD Touch Screen For Clinics and Hospital |
| SKU | PSKU0146 |
| Size | 2120*965*450-740mm |
| Packing Size of set | 2090*1100*430mm (1 set per carton) |
| Loading capacity | 250kg / 551lbs |
Product Description
1. Features:
1) Power supply voltage: single-phase three-wire
2) Power frequency: 50Hz±1Hz
3) Nominal current: 400ma
4) Maximum output power: 32kW
5) Working frequency: ≥300kHz
6) Maximum peak tube voltage: 125kV
7) Detector: CareRay1800Le
8) Sensor/Scintillator: Silicon/Cesium
9) Iodide Dimensions: 460*460*15mm
10) Spatial resolution: 3.6lp/mm
11) A/D conversion: 16bits
12) Pixel size: 140 μm
13) Effective area: 17*17inches
