Iray Mammo 1012C Medical DR flat Panel Detector X-ray Portable Flat Panel Detector Digital Wireless DR FLAT PANEL DETECTOR
Model: PSKU0126
1. Features:1) Cassette size conform with ISO 40902) 85 μm pixel pitch with 16-bit ADC3) Switchable gain settings for variable sensitivity4) Compact design for easy integration5) Dynamic Range (dB): >766) Detector Technology: Am...
Product Parameters
| Parameter | Description |
|---|---|
| Product Name | Iray Mammo 1012C Medical DR flat Panel Detector X-ray Portable Flat Panel Detector Digital Wireless DR FLAT PANEL DETECTOR |
| SKU | PSKU0126 |
| Size | 2120*965*450-740mm |
| Packing Size of set | 2090*1100*430mm (1 set per carton) |
| Loading capacity | 250kg / 551lbs |
Product Description
1. Features:
1) Cassette size conform with ISO 4090
2) 85 μm pixel pitch with 16-bit ADC
3) Switchable gain settings for variable sensitivity
4) Compact design for easy integration
5) Dynamic Range (dB): >76
6) Detector Technology: Amorphous Silicon
7) Scintillator: CsI
8) Active Area (mm): 235 × 290
9) Pixel Matrix: 2762 × 3408
10) Pixel Pitch (μm): 85
11)Maximum Frame Rate (fps): N.A
12) AD Conversion (bit): 16
13) Dynamic Range (dB): >76
